SYM |
DESCRIPTION
|
QTY. |
PART
NUMBER |
1
2
3
4
5 |
Eng.Mnt Ring
Clipper Seal, Brg. Cap
Bearing Cap
Gasket, Brg. Cap
Clipper Seal, Suction |
1
1
1
1
1 |
SC-40-07
SL-10-07
SC-20-07
G-15-07
SL-15-07 |
6
7
8
9
10 |
Lock Nut, Packing Gland
Pakcing Gland(set)
Bolt, Packing Gland 3/8 x 1-3/4
Packing Rings
Bolt, Bowl 1/2 x 1-1/2 |
2
1
2
4
8 |
F-10-LN
SC-25-07
F-32-CS
SC-30-07
F-41-CS |
11
12
13
14
15 |
Lockwasher
Snap Ring, Bowl
Clipper Seal, Bowl
Bowl Bearing
Bowl Plug |
8
1
2
2
1 |
F-40-LW
SC-92-01
SL-20-03
B-15-02
SC-90-01 |
16
17
18
19
20 |
Grease Zert
Lockwasher
Bolt 5/16 x 1
Bolt 5/16 x 2
Lockwasher |
1
8
8
4
4 |
SC-89-01
F-20-LW
F-52-CS
F-23-CS
F-20-LW |
21
22
23
24
25 |
Bolt 5/16 x 1
Lockwasher
Hand Hole Cover
O-Ring
Gasket * |
4
4
1
1
1 |
F-52-CS
F-20-LW
SC-15-01
0-10-01
G-20-01 * |
26
27
28
29
30 |
Insluator, Wear Ring
Wear Ring
Impeller
Bowl
Grease Zert |
1
1
1
1
1 |
IM-60-04
IM-50-04
IM-??-??
SC-91-01
SC-88-01 |
31
32
33
34
35 |
Suction Piece
Hose Barb
Pumpshaft
Snap-Ring Shaft
Thrust Washer |
1
1
1
1
1 |
SC-10-01
SC-45-07
SH-11-07
SH-15-07
SH-20-05 |
36
37
38
39
40 |
Thrust Bearing
Slinger Ring
Impeller Shim
Impeller Key
Impeller Locknut |
1
1
AR
1
1 |
B-10-07
SH-25-07
SH-40-07
SH-30-07
SH-35-07 |
