SYM.
|
DESCRIPTION
|
QTY.
|
PART
NO.
|
1
2
3
4
5
|
Suction
Piece
Pumpshaft
Grease Zert
Bearing Cap
Clipper Seal,
Brg. Cap |
1
1
1
1
1
|
SC1003
SH1007
SC8801
SC2007
SL1007
|
6
7
8
9
10
|
Snap-
Ring, Shaft
Thrust Bearing
Bolt 5/16 x
2
Gasket, Brg.
Cap
Clipper Seal,
Suction |
1
1
4
1
1
|
SH1507
B1007
F23CS
G1507
SL1507
|
11
12
13
14
15
|
Lock
Nut, Packing Gland
Bolt, Packing
Gland 3/8 x 1-3/4
Packing Gland
(set)
Packing Rings
Wear Ring (req.
IM6004 insulator) |
2
2
1
4
1
|
F10LN
F32CS
SC2507
SC3007
IM5004
|
16
17
18
19
20
|
O-Ring
Bolt 5/16 x
1
Lockwasher
Slinger Ring
Hand Hole Cover |
1
4
4
1
1
|
O1003
F52CS
F20LW
SH2507
SC1703
|
21
22
23
24
25
|
Impeller
Impeller Key
Impeller Locknut
Impeller Shim
Gasket* |
1
1
1
AR
1
|
IM ??-??
SH3007
SH3507
K4007
G2001*
|
26
27
28
29
30
|
Bolt,
Bowl 1/2 x 1-1/2
Bowl**
Bowl Sleeve,Seal,
& Snap Ring
Bowl Bearing
& Bowl Plug
Gasket, Nozzle
Housing |
8
1
0
0
1
|
F41CS
SC9103**
CALL
CALL
G2507
|
31
32
33
34
35
|
Nozzle
Housing
Capscrew (5/16
x 1)
Lockwasher
Tiller Pin
Woodruff Key |
1
11
11
1
2
|
R1007
F52CS
F20LW
BN2410
R5507
|
36
37
38
41
42
|
Square
Head Set Screw
Lower Nozzle
Pin
3/4" Nyliner
Bearing
Nozzle
Reverse Bucket |
1
1
4
1
1
|
F12SS
BN2510
B2007
R1703
R2103
|
43
44
45
46
47
|
Rudder
Rudder Bolt
Lockwasher
3/8" Nyliner
Pivot Pin, Reverse
Bucket |
1
4
4
1
1
|
R2505
F10CS
F10LW
B2105
R5005
|
48
49
51
52
53
|
O-Ring, Nozzle
Reverse Bucket Pin
Thrust Washer
Tiller Arm
Square Head Set Screw |
1
2
1
1
1
|
O1505
R4601
SH2005
R3003
F11SS
|
